Mark T Posted July 30 Share Posted July 30 25 minutes ago, mowerman said: Right???????? Kinda like drawing on The Mona Lisa with a Sharpie. In reality, truck's one of a small handful of those that'll ever look like that . Not easy finding someone to make you're vision reality, when to this point Matt was pretty much in control of the outcome. I know I'd be a bundle of nerves. 1 Quote Link to comment Share on other sites More sharing options...
Popular Post yarnall Posted July 30 Popular Post Share Posted July 30 My father had a truck painted a couple of years ago and I offered to have it striped and letter. He declined. I asked a couple more times and finally he said it looks new without lettering. He was used to new trucks coming into the fleet all nice and clean. Then they were lettered and were just another truck in the fleet. Mike. 3 Quote Link to comment Share on other sites More sharing options...
Popular Post mattb73lt Posted August 22 Author Popular Post Share Posted August 22 I had a weird thing happen with the transmission this week. Went out with the truck two Saturdays ago to put some miles on it. Get back and I smell some gear oil as I get out. I don't think much of it and go over to my neighbors for a few beers. Come back about two hours later and as I'm locking up the truck I see a huge puddle of gear oil under the bell housing. Pour some speedy dry on it and put a drip pan under it loaded with more speedy dry to catch what's dripping out. Next day. I clean up the mess and start investigating and from what I see it's coming from behind the clutch brake, on the counter shaft. I run it and watch and it's still dripping. I didn't have time to work on it then, so I drain it down to stop the leak. I thought I could get at it through the lower opening on the bell housing and change the seal that way. Nope, not enough room to get up in there and pull the parts down. The only way to fix this is to pull the transmission out and now that it's all together I can't do that in my yard. I was able to get a friend to allow me access to his shop and transmission jack. That was supposed to happen this morning. Late yesterday in preparation for today, I refilled the transmission and packed up my tools to do this. I was able to get a new seal and a speedy sleeve to replace the old ones. I figure screw it I'll take for a ride for the hell of it. Get back late yesterday after my joy ride and slide a clean drip pan under it. No drips/leaks, even after a few hours. Call my friend and ask for a raincheck due to work popping up for today. Check the drip pan this morning, no drips. Screw it, I take the truck to work, about a 35 mile run, and park it. Before I leave on my trip, I check the pavement under the truck, again dry. Come back seven hours later, still dry!! I can't figure this one out. It hemorrhaged almost a gallon of gear oil in my yard and now it's ok?? It's dry not even a drop hanging, ready to drip. On a bright note, I did finally get to drive the truck at night, with all the lights working. 5 2 2 Quote Link to comment Share on other sites More sharing options...
mowerman Posted August 22 Share Posted August 22 That’s just really weird looks great bud. Thanks for that… bob Quote Link to comment Share on other sites More sharing options...
Freightrain Posted August 22 Share Posted August 22 I forget, what transmission? Not that it matters that it fixed itself. 1 Quote Larry 1959 B61 Liv'n Large...................... Charter member of the "MACK PACK" Link to comment Share on other sites More sharing options...
mattb73lt Posted August 22 Author Share Posted August 22 Triplex, TRTL-720. Still dry this morning and still scratching my head. 1 Quote Link to comment Share on other sites More sharing options...
Popular Post tjc transport Posted August 22 Popular Post Share Posted August 22 maybe the vent got blocked and it pressurized the trans pumping the oil past the seal? 7 Quote when you are up to your armpits in alligators, it is hard to remember you only came in to drain the swamp.. Link to comment Share on other sites More sharing options...
mattb73lt Posted August 22 Author Share Posted August 22 Thats a thought, but it was still leaking statically for a long time before I could get it drained down? 1 Quote Link to comment Share on other sites More sharing options...
tjc transport Posted August 22 Share Posted August 22 it will leak as long as there is pressure in the trans. once it cools off, or the pressure is released it will stop. Quote when you are up to your armpits in alligators, it is hard to remember you only came in to drain the swamp.. Link to comment Share on other sites More sharing options...
Mark T Posted August 22 Share Posted August 22 No chance it was accidently over filled ? 1 Quote Link to comment Share on other sites More sharing options...
1961H67 Posted August 23 Share Posted August 23 I had a duplex get some old silicone in the drain for the front input shaft bearing, it was running oil down to the bearing but couldn’t drain back into the case , and was running oil out the front input, I pulled the cap and blew all the feed and drain holes out , no leaks. Just an idea., could the restriction passed on. And let it be draining the way it should??? . 2 Quote Link to comment Share on other sites More sharing options...
mechohaulic Posted August 23 Share Posted August 23 23 hours ago, mattb73lt said: I had a weird thing happen with the transmission this week. Went out with the truck two Saturdays ago to put some miles on it. Get back and I smell some gear oil as I get out. I don't think much of it and go over to my neighbors for a few beers. Come back about two hours later and as I'm locking up the truck I see a huge puddle of gear oil under the bell housing. Pour some speedy dry on it and put a drip pan under it loaded with more speedy dry to catch what's dripping out. Next day. I clean up the mess and start investigating and from what I see it's coming from behind the clutch brake, on the counter shaft. I run it and watch and it's still dripping. I didn't have time to work on it then, so I drain it down to stop the leak. I thought I could get at it through the lower opening on the bell housing and change the seal that way. Nope, not enough room to get up in there and pull the parts down. The only way to fix this is to pull the transmission out and now that it's all together I can't do that in my yard. I was able to get a friend to allow me access to his shop and transmission jack. That was supposed to happen this morning. Late yesterday in preparation for today, I refilled the transmission and packed up my tools to do this. I was able to get a new seal and a speedy sleeve to replace the old ones. I figure screw it I'll take for a ride for the hell of it. Get back late yesterday after my joy ride and slide a clean drip pan under it. No drips/leaks, even after a few hours. Call my friend and ask for a raincheck due to work popping up for today. Check the drip pan this morning, no drips. Screw it, I take the truck to work, about a 35 mile run, and park it. Before I leave on my trip, I check the pavement under the truck, again dry. Come back seven hours later, still dry!! I can't figure this one out. It hemorrhaged almost a gallon of gear oil in my yard and now it's ok?? It's dry not even a drop hanging, ready to drip. On a bright note, I did finally get to drive the truck at night, with all the lights working. tri-plex having a push clutch;; throw out fork has the finger on bottom which pushes against lower counter shaft equipped with clutch brake assembly ??? old 3 piece clutch brake (2 fiber 1 steel intermediate plate ) or updated 1 piece brake ?? input shaft have the hole with short pin acting as seal ? have seen clogged vents , none of which where bad enough to pressurize transmission to point of pumping that much oil then stop. but clogged vent will be #1 thought 2 Quote Link to comment Share on other sites More sharing options...
Popular Post mattb73lt Posted August 23 Author Popular Post Share Posted August 23 I don’t think so. I drained a little bit less than 4 gallons out of it. Capacity is a little over four. The only thing plumbed into it is the PTO/ pump assembly and there’s a 1/4” drain hole in the PTO case so it can’t transfer there, it would just drain out. I don’t think it was pressurized, there’s a big vent on the top cover and the main stick isn’t air tight. Still dry tonight. Tomorrow I’ll drain it again and put fresh gear oil in it. The weekend is shaping up that I might make the Bolton show on Sunday. My boss has the big DreamRide weekend he sponsors for his Special Olympics fundraiser. It’s a three day event and I think I’m going to skate on Sunday. 3 Quote Link to comment Share on other sites More sharing options...
Freightrain Posted August 23 Share Posted August 23 My very worn out, loose, clanky, triplex leaks from the aux shift arms. At least that is one main spot that runs down the side. I'm sure the o rings on those shafts are likely rock hard. Thus the reason I want to replace it with something. 2 Quote Larry 1959 B61 Liv'n Large...................... Charter member of the "MACK PACK" Link to comment Share on other sites More sharing options...
mowerman Posted August 23 Share Posted August 23 mine im sure are the same way,,,especially since trans has been sitting outside for a long long time.im fixing on looking at them before i put it in,trans was supposably, rebuilt a while back,..bob Quote Link to comment Share on other sites More sharing options...
mowerman Posted August 23 Share Posted August 23 and matt,,,,love those side markers,,,,great touch,,,must have missed the post,,,when you put them there,,,bob Quote Link to comment Share on other sites More sharing options...
mechohaulic Posted August 23 Share Posted August 23 11 hours ago, mattb73lt said: I don’t think so. I drained a little bit less than 4 gallons out of it. Capacity is a little over four. The only thing plumbed into it is the PTO/ pump assembly and there’s a 1/4” drain hole in the PTO case so it can’t transfer there, it would just drain out. I don’t think it was pressurized, there’s a big vent on the top cover and the main stick isn’t air tight. Still dry tonight. Tomorrow I’ll drain it again and put fresh gear oil in it. The weekend is shaping up that I might make the Bolton show on Sunday. My boss has the big DreamRide weekend he sponsors for his Special Olympics fundraiser. It’s a three day event and I think I’m going to skate on Sunday. had this truck been running daily in the mud/dirt etc top vent being clogged ;pressure slim chance. the 73 in better then new factory clean = no clogged vent . strange things do happen in the world of mechanics. slight drip : maybe. massive amount which stops with transmission still holding oil ?? just puts that slight fear going down the road :will it happen again, miles from house". foreign matter finds it's way between seal THEN leaves ?? side note: received a picture showing one of Mahan's Macks heading up rte61;; trip to Matt 's in Bethlehem ?? 2 Quote Link to comment Share on other sites More sharing options...
Popular Post mattb73lt Posted August 23 Author Popular Post Share Posted August 23 3 hours ago, Freightrain said: My very worn out, loose, clanky, triplex leaks from the aux shift arms. At least that is one main spot that runs down the side. I'm sure the o rings on those shafts are likely rock hard. Thus the reason I want to replace it with something. I went completely through the whole transmission. Replaced all the roller and taper bearings, seals and re-shimmed the shafts. Rebuilt the shift covers, split the cases. All new gaskets and seals. The only thing not replaced were the shell bushings on the sliding gears, which you can’t get anywhere. Everything was cleaned and inspected. It’s been very dry, so far. There’s a little noise from it, but it doesn’t howl. Shifts very smoothly. The original odometer had about 375K miles, when it stopped working. Just an odd occurrence so far. I’ll get it ready for Bolton. That’ll be its longest run so far. 2500 miles on the clock so far with no issues other than this one. 4 1 Quote Link to comment Share on other sites More sharing options...
mattb73lt Posted August 23 Author Share Posted August 23 1 hour ago, mowerman said: and matt,,,,love those side markers,,,,great touch,,,must have missed the post,,,when you put them there,,,bob The ones on the bed? They were original to it. Thinking about adding some more, but I may just leave it as is. There all new LED types and all fresh wiring. 1 Quote Link to comment Share on other sites More sharing options...
mowerman Posted August 23 Share Posted August 23 lol three markers under the cab would probably dress it up on a chrome panel but then again it might overkill ….. bob Quote Link to comment Share on other sites More sharing options...
Popular Post mattb73lt Posted August 24 Author Popular Post Share Posted August 24 Swapped the fluid today, all new and fresh. Full to the proper level. Ran it 20 minutes and rechecked the level, it’s spot on. Just came home now and checked my drip pan. Not a drop. Tomorrow, off to DreamRide and Sunday off to the Bolton Fairgrounds show in Massachusetts. 2 1 Quote Link to comment Share on other sites More sharing options...
cruiseliner64 Posted August 24 Share Posted August 24 Wow thats some story and a beautiful truck.good luck with it and keep us up to date with your progress. Paul 2 Quote Link to comment Share on other sites More sharing options...
Popular Post mrsmackpaul Posted August 24 Popular Post Share Posted August 24 My thoughts are really simple as that's my style Unlikely a blocked vent, most gearboxes aren't very airtight thru the gear stick etc However, my experience or lack there of tells when things like this happen the oil is frothing up in a gearbox The air bubbles take while to go down and as such the oil runs out for a while once stopped If this is the case you sort of need to be careful as the bearings might be running in froth and not oil Good news is, there's anti froth agent's to add to the oil and anti froth oil Sometimes when a PTO is added with a idler gear that runs all the time it can cause this Maybe just add sdome anti froth additibe Paul 4 Quote Link to comment Share on other sites More sharing options...
Popular Post mattb73lt Posted August 25 Author Popular Post Share Posted August 25 Big day for the B73. Did the whole DreamRide motorcade through several towns in the central Connecticut area. About an 18 mile course with hundreds of cars, fire engines hauling Special Olympic athletes, about 600 of them paired up with drivers and cars. Truck ran perfectly over the route with no issues, but lots of shifting and Jake brake action. A long and fun day. I even rescued one of our vintage State Police cars the decided the quit about 1/2 mile from the end. A really good day. Tomorrow off to the Lancaster, MA show. It should be another great day. Fingers crossed for no issues! 5 4 Quote Link to comment Share on other sites More sharing options...
mrsmackpaul Posted August 25 Share Posted August 25 Great stuff Paul Quote Link to comment Share on other sites More sharing options...
