Ricky Beals Posted March 4, 2022 Share Posted March 4, 2022 When bringing the 2000 rd688 home yesterday I was watching the air gauge and the red and green would peg 120. The green would stay at 120 but the red would move down to 100 then bounce back to 120 just to start back down to 100. when shutting truck off I can hear a lot of air coming out of the ac vent in middle of truck. Any idea where this is coming from and how to access it? Thanks Ricky Quote Link to comment https://www.bigmacktrucks.com/topic/69322-couple-air-leak-questions/ Share on other sites More sharing options...
mechohaulic Posted March 4, 2022 Share Posted March 4, 2022 the red gauge is cycling due to the air leak. far as the vent leak i'll take a shot at the solenoid is malfunctioning . not to knowledgeable on the new truck systems. when shut off the electrical system for ac should be off; fan still works, i'd say system live and shouldn't be. to cycle the system must be large leak. Quote Link to comment https://www.bigmacktrucks.com/topic/69322-couple-air-leak-questions/#findComment-490829 Share on other sites More sharing options...
Ricky Beals Posted March 4, 2022 Author Share Posted March 4, 2022 Didn’t really understand your answer. The ac system is off, fan is off. When I kill the truck I can hear air in that area and hear it best from the bottom vents below the AC controls. I’m thinking it’s something behind that ac box but have no idea what it is. What solenoid are you thinking is malfunctioning? Quote Link to comment https://www.bigmacktrucks.com/topic/69322-couple-air-leak-questions/#findComment-490841 Share on other sites More sharing options...
Popular Post Onyx610 Posted March 4, 2022 Popular Post Share Posted March 4, 2022 Take the cover off the box and look for something that looks like this…it also may be metal. 3 Quote Link to comment https://www.bigmacktrucks.com/topic/69322-couple-air-leak-questions/#findComment-490842 Share on other sites More sharing options...
Onyx610 Posted March 4, 2022 Share Posted March 4, 2022 I think mechohaulic thought you meant the the fan was staying on when the truck was off when you said air was coming out of the ac vent. Quote Link to comment https://www.bigmacktrucks.com/topic/69322-couple-air-leak-questions/#findComment-490843 Share on other sites More sharing options...
Joey Mack Posted March 4, 2022 Share Posted March 4, 2022 Onyx is on to something.. when it is aired up, shut it down... then move the vent selector one click at a time in both directions. if the air leak changes or stops, do what Onyx said. there is a little air piston and the controls also have spaghetti lines going to them and they end to leak, they are push lock type fittings. jojo 1 Quote Link to comment https://www.bigmacktrucks.com/topic/69322-couple-air-leak-questions/#findComment-490848 Share on other sites More sharing options...
Ricky Beals Posted March 4, 2022 Author Share Posted March 4, 2022 Ok when I turn the control to Ac Max,Norm,Vent,Heat I can hear air. If I turn it to Off or Deff I can’t hear air. So is there one of those items that ONYX610 posted or multiple? Thanks Quote Link to comment https://www.bigmacktrucks.com/topic/69322-couple-air-leak-questions/#findComment-490887 Share on other sites More sharing options...
Onyx610 Posted March 4, 2022 Share Posted March 4, 2022 It’s that turd Quote Link to comment https://www.bigmacktrucks.com/topic/69322-couple-air-leak-questions/#findComment-490888 Share on other sites More sharing options...
Onyx610 Posted March 4, 2022 Share Posted March 4, 2022 And pry a couple of other little air lines… 1 Quote Link to comment https://www.bigmacktrucks.com/topic/69322-couple-air-leak-questions/#findComment-490890 Share on other sites More sharing options...
R.E.D Posted March 5, 2022 Share Posted March 5, 2022 Just wanted to add that your ac system was manufactured by red dot.. probably better to go to them for parts than ..mack/Volvo.. 1 Quote Link to comment https://www.bigmacktrucks.com/topic/69322-couple-air-leak-questions/#findComment-490896 Share on other sites More sharing options...
Joey Mack Posted March 5, 2022 Share Posted March 5, 2022 good call. I wonder if it would be cheaper than MackVo.. for the same parts.. you may as well buy a new fan speed switch and the plug on the truck side of that wire harness... they always get hot from a loose connection then they melt the plug, which can cause a short.... Indak makes the switch.. jojo 1 Quote Link to comment https://www.bigmacktrucks.com/topic/69322-couple-air-leak-questions/#findComment-490899 Share on other sites More sharing options...
Onyx610 Posted March 5, 2022 Share Posted March 5, 2022 (edited) Yup never seen one that wasn’t melted Edited March 5, 2022 by Onyx610 Spelling Quote Link to comment https://www.bigmacktrucks.com/topic/69322-couple-air-leak-questions/#findComment-490900 Share on other sites More sharing options...
