james j neiweem Posted January 19, 2023 Share Posted January 19, 2023 Seems like V**&&%/Mack should have solved the injector cup Issues by now. Is it so? Quote Link to comment https://www.bigmacktrucks.com/topic/72315-injector-cup-issues/ Share on other sites More sharing options...
Mackpro Posted January 19, 2023 Share Posted January 19, 2023 We have not had any cup issues with any of our common rail engines. A few injector issues but none cup related. Still same injector cup but only 3 injectors are driven off the camshaft, which is why they fail. The camshaft/rocker arm rocks the injector back and forth eventually causing it to leak. That part is still the same but now you only have a 3 injectors to worry about leaking instead of 6. Still a crappy set up. 1 1 Quote Link to comment https://www.bigmacktrucks.com/topic/72315-injector-cup-issues/#findComment-523136 Share on other sites More sharing options...
upsman Posted January 20, 2023 Share Posted January 20, 2023 Need to retorque the injector hold downs whenever you do an overhead so the injector doesn’t start pounding on the cup. Quote Link to comment https://www.bigmacktrucks.com/topic/72315-injector-cup-issues/#findComment-523229 Share on other sites More sharing options...
fjh Posted January 20, 2023 Share Posted January 20, 2023 7 hours ago, upsman said: Need to retorque the injector hold downs whenever you do an overhead so the injector doesn’t start pounding on the cup. Might help ! But Proper HPCR would solve the problem ! However can teach an old dog new tricks! Its to bad they can't see the forest for the trees! But again if they leave it the way it is they can still sell injectors and keep Mack pro busy for years to come! 🤣 Quote Link to comment https://www.bigmacktrucks.com/topic/72315-injector-cup-issues/#findComment-523294 Share on other sites More sharing options...
upsman Posted January 20, 2023 Share Posted January 20, 2023 Supposedly late 2018’s the problem was corrected…. Quote Link to comment https://www.bigmacktrucks.com/topic/72315-injector-cup-issues/#findComment-523298 Share on other sites More sharing options...
fjh Posted January 20, 2023 Share Posted January 20, 2023 3 minutes ago, upsman said: Supposedly late 2018’s the problem was corrected…. half corrected! 🙃 1 Quote Link to comment https://www.bigmacktrucks.com/topic/72315-injector-cup-issues/#findComment-523300 Share on other sites More sharing options...
Mackpro Posted January 21, 2023 Share Posted January 21, 2023 I guess I should not have praised the common rail injectors on Thursday. Had a #.2 pumping injector go down . At least it wasn’t a cup issue. If you ever get multiple injector faults check for DEF in the fuel . Lucky it was just a faulty injector this time . But we have had drivers talking on the phone/ distracted while fueling up and put DEF in the fuel tanks and eat the injectors up 1 1 Quote Link to comment https://www.bigmacktrucks.com/topic/72315-injector-cup-issues/#findComment-523432 Share on other sites More sharing options...
Onyx610 Posted January 21, 2023 Share Posted January 21, 2023 1 hour ago, Mackpro said: I guess I should not have praised the common rail injectors on Thursday. Had a #.2 pumping injector go down . At least it wasn’t a cup issue. If you ever get multiple injector faults check for DEF in the fuel . Lucky it was just a faulty injector this time . But we have had drivers talking on the phone/ distracted while fueling up and put DEF in the fuel tanks and eat the injectors up Lol, damn I always thought DEF in the fuel was an extremely expensive mistake as it pretty much destroyed majority of the fuel system. Quote Link to comment https://www.bigmacktrucks.com/topic/72315-injector-cup-issues/#findComment-523448 Share on other sites More sharing options...
Mackpro Posted January 21, 2023 Share Posted January 21, 2023 14 minutes ago, Onyx610 said: Lol, damn I always thought DEF in the fuel was an extremely expensive mistake as it pretty much destroyed majority of the fuel system. Yes. DEF in the fuel is a super expensive mistake. Mack has a bulletin on every thing that’s needs to be replaced and cleaned. Quote Link to comment https://www.bigmacktrucks.com/topic/72315-injector-cup-issues/#findComment-523453 Share on other sites More sharing options...
Onyx610 Posted January 21, 2023 Share Posted January 21, 2023 I’ll have to check that out. Quote Link to comment https://www.bigmacktrucks.com/topic/72315-injector-cup-issues/#findComment-523454 Share on other sites More sharing options...
Mackpro Posted January 22, 2023 Share Posted January 22, 2023 9 hours ago, Onyx610 said: I’ll have to check that out. https://static.nhtsa.gov/odi/tsbs/2021/MC-10186476-0001.pdf Here the bulletin on what need to be replaced and cleaned . Quote Link to comment https://www.bigmacktrucks.com/topic/72315-injector-cup-issues/#findComment-523521 Share on other sites More sharing options...
Onyx610 Posted January 22, 2023 Share Posted January 22, 2023 Thanks for posting that, I’m out of likes for today haha. Crazy how much havoc that shit can cause. I always thought that once it made it into the tank it was essentially a whole fuel system replacement. Didn’t know def settled in fuel like that either. Have you had to do one of these jobs before? Must take a long time to do. Quote Link to comment https://www.bigmacktrucks.com/topic/72315-injector-cup-issues/#findComment-523522 Share on other sites More sharing options...
Mark T Posted January 22, 2023 Share Posted January 22, 2023 9 hours ago, Onyx610 said: Thanks for posting that, I’m out of likes for today haha. Crazy how much havoc that shit can cause. I always thought that once it made it into the tank it was essentially a whole fuel system replacement. Didn’t know def settled in fuel like that either. Have you had to do one of these jobs before? Must take a long time to do. DEF is basically mostly water. It's like 32.5% urea (or something like that) Quote Link to comment https://www.bigmacktrucks.com/topic/72315-injector-cup-issues/#findComment-523530 Share on other sites More sharing options...
fjh Posted January 22, 2023 Share Posted January 22, 2023 9 hours ago, Onyx610 said: Thanks for posting that, I’m out of likes for today haha. Crazy how much havoc that shit can cause. I always thought that once it made it into the tank it was essentially a whole fuel system replacement. Didn’t know def settled in fuel like that either. Have you had to do one of these jobs before? Must take a long time to do. Wow yup pretty pricey At least 12 grand worth of parts not to mention the labour! No get out of jail free card with any Volvo repair thou! Quote Link to comment https://www.bigmacktrucks.com/topic/72315-injector-cup-issues/#findComment-523531 Share on other sites More sharing options...
Onyx610 Posted January 22, 2023 Share Posted January 22, 2023 2 hours ago, Mark T said: DEF is basically mostly water. It's like 32.5% urea (or something like that) Yea that’s true Quote Link to comment https://www.bigmacktrucks.com/topic/72315-injector-cup-issues/#findComment-523535 Share on other sites More sharing options...
