Gambi80 Posted April 18, 2009 Share Posted April 18, 2009 Quick question about the engine shutdown/electonic malfuntion light...what else would trigger it besides low coolant? The other night it was coming on on me every now and then. All the fluids are fine and there was no shutdown and/or power loss. Truck is a 97 CH. Quote Ever wonder how a blind person knows when to stop wiping? Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/ Share on other sites More sharing options...
Mackpro Posted April 18, 2009 Share Posted April 18, 2009 The only time both lights come on is for low coolant, (except for 2008 and up DPF equipped Macks). Could be a coolant sensor wire shorted in the harness on the engine. Quote Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/#findComment-33973 Share on other sites More sharing options...
fjh Posted April 18, 2009 Share Posted April 18, 2009 Quick question about the engine shutdown/electonic malfuntion light...what else would trigger it besides low coolant? The other night it was coming on on me every now and then. All the fluids are fine and there was no shutdown and/or power loss. Truck is a 97 CH.Oil preasure / coolant overheat and low coolant set the lights off on a 97!If you have the inactive codes check that will tell the tail. Quote Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/#findComment-33978 Share on other sites More sharing options...
sscochrane Posted June 30, 2009 Share Posted June 30, 2009 DroverG/day mate,I have a 95 model that is shuting down aswell, did you solve the problem? as it has me stumped.Quick question about the engine shutdown/electonic malfuntion light...what else would trigger it besides low coolant? The other night it was coming on on me every now and then. All the fluids are fine and there was no shutdown and/or power loss. Truck is a 97 CH. Quote Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/#findComment-37432 Share on other sites More sharing options...
fjh Posted July 1, 2009 Share Posted July 1, 2009 DroverG/day mate,I have a 95 model that is shuting down aswell, did you solve the problem? as it has me stumped.Quick question about the engine shutdown/electonic malfuntion light...what else would trigger it besides low coolant? The other night it was coming on on me every now and then. All the fluids are fine and there was no shutdown and/or power loss. Truck is a 97 CH.If your unit is shutting down on low coolant high water temp or low oil psi both lights will light eml and the shut down light.Bad sensor on any of three sensors or a bad wire.We set all of our customer engine to NOT shut down on low coolant. its easier that way only two choices.Both of which will show on gauges. Quote Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/#findComment-37477 Share on other sites More sharing options...
Jasperando Posted December 15, 2017 Share Posted December 15, 2017 G/day drover,my vision mack 3007 model always show engine short whenever the engine is hot and it drives fine before engine heat up.oil pump well, no water leakage. Pls help me out am getting frustrated. Regards Quote Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/#findComment-387483 Share on other sites More sharing options...
Bigryno Posted July 25, 2019 Share Posted July 25, 2019 97 mack ch600 or 613 I guess. Shuts down when I stop. Shutdown light comes on and the truck dies but only when I slow to a stop. Runs fine til I come to a stop. It dies but starts right back and away I go. Help please Quote Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/#findComment-428681 Share on other sites More sharing options...
Keffer inc Posted August 8, 2019 Share Posted August 8, 2019 You can check the code. With your cruise control switch OFF, press the set button and the electronic malfunction light will blink the code. So let's say it's code 4-1, the light will blink 4 times, pause a second or two, and blink 1 time, then go back to constant. If there is more than one code, press the bottom again, and the next code will blink. Keep doing that until you get back to the first blink code. Google Mack E7 codes for the code list Quote Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/#findComment-429626 Share on other sites More sharing options...
Wasteremover Posted September 15, 2019 Share Posted September 15, 2019 I'm getting a 1-4 code..can anyone tell me where to find the ambient air temp sensor on an 03 ch612 Thanks Quote Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/#findComment-432186 Share on other sites More sharing options...
Mack Technician Posted September 16, 2019 Share Posted September 16, 2019 Your near a transition year......that one I think it was up by the bottom of the radiator taking first grab at draft air before radiator got to it. Quote Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/#findComment-432190 Share on other sites More sharing options...
Wasteremover Posted September 16, 2019 Share Posted September 16, 2019 Thanks I'll check that tomorrow Quote Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/#findComment-432193 Share on other sites More sharing options...
880joe Posted September 16, 2019 Share Posted September 16, 2019 My 99 CH is about the middle of rear head on left side on the intake manifold Quote Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/#findComment-432194 Share on other sites More sharing options...
Backitup&dumpitllc Posted December 8, 2019 Share Posted December 8, 2019 On 7/24/2019 at 7:25 PM, Bigryno said: 97 mack ch600 or 613 I guess. Shuts down when I stop. Shutdown light comes on and the truck dies but only when I slow to a stop. Runs fine til I come to a stop. It dies but starts right back and away I go. Help please My truck does the same thing only while stopping and turns right back on 2000 CX613 E7-460 Quote Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/#findComment-437581 Share on other sites More sharing options...
ksrolloff Posted December 8, 2019 Share Posted December 8, 2019 had a 1999 rd do this same thing, the oil pressure sensor on the top of filter housing was the issue. Quote Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/#findComment-437587 Share on other sites More sharing options...
Stitch117 Posted December 11, 2019 Share Posted December 11, 2019 (edited) Have a 91 CH613 it has both Electronic and Shut down Lights come on, truck just keeps running any suggestions? Edited December 11, 2019 by Stitch117 Added Photo Quote Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/#findComment-437837 Share on other sites More sharing options...
alex g Posted December 11, 2019 Share Posted December 11, 2019 Had similar issue with my 2000 CH. Check coolant level. Good luck Quote Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/#findComment-437844 Share on other sites More sharing options...
Bullheaded Posted December 12, 2019 Share Posted December 12, 2019 The mass ground point inside dash on driver side A pillar. Clean and check your grounds. At least that's what it was on my 2000 CH when I used to have it. Always had the malfunction light coming on and off and the truck randomly shutting off and starting right back up while driving down the highway. Dealer never could figure it out. They changed all kinds of harnesses and ecm. Was just the mass ground. Found out many years later. Quote Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/#findComment-437850 Share on other sites More sharing options...
Stitch117 Posted December 12, 2019 Share Posted December 12, 2019 Thanks guys will check that out! Never have had the truck shut down and the lights shut off time to time. Quote Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/#findComment-437857 Share on other sites More sharing options...
7axleMike Posted October 16 Share Posted October 16 On 12/8/2019 at 1:16 AM, Backitup&dumpitllc said: My truck does the same thing only while stopping and turns right back on 2000 CX613 E7-460 Quote Link to comment https://www.bigmacktrucks.com/topic/9079-engine-shutdownelectronic-malfuntion-lights/#findComment-560181 Share on other sites More sharing options...
